Newlite IndoorLED VB 1700p 630W - 6Bars / 8Bars
Newlite Indoor LED Vegetative Bloom 1700 µmol/s 630 Watt - 6 Bars / 8 Bars
Newlite LED IndoorLED VB 1700P 630 Watt fixtures are light emitting diode (LED) devices for both the growing and flowering process.
The panels illuminate a cultivation area of 120 cm x 120 cm and are optimized to work at a height between 25 cm and 40 cm above the top of the plants. The Newlite LED IndoorLED VB lamps deliver light intensity within a PPFD range of 900 µmol/s/m², which is increased to PPFD 1200 µmol/s/m² when multiple fixtures are used.
The lamp is made of aluminum. The LEDs are heat dissipated in aluminum bars to maintain efficient passive heat transfer and dissipation without the use of fans, eliminating noise and optimizing energy consumption. This passive dissipation system eliminates potential failures and maintains the critical temperature of the LEDs to achieve long life at optimum levels.
Relevant features | |
Professional LED lighting for technical crops. | |
Perfect spectrum for the complete process: seeds, cuttings, vegetative and flowering stages. | |
Optimum production in terms of weight and quality. | |
It presents a power controller with 250 W - 380 W - 500 W - 630 W - EXT/OFF for the 6 Bar and 25% - 50% - 75% - 100% - EXT / OFF for the 8 bar | |
EXT signal input for centralised control in large installations. | |
Wide input voltage for correct operation in any installation. | |
IP66 protection rating for extremely humid environments. | |
Spectrum Spectrum for the complete development of the plant, from the preliminary germination or rooting stages to the vegetative and flowering stage. The red peak at 680 nm favours potent flowering which, together with the blue peak at 300 nm, yields compact, dense plants. |
Technical specifications |
- Power: 630W ± 5%
- Input Voltage: 100-277 VAC
- Input Frequency: 50-60Hz
- Power factor> 0.95 cos ?
- Power selector positions: 25% - 50% - 75% - 100% - EXT / OFF
- The Chips used are: White: Samsung LM301H 670nm Red Peak: Philips Lumileds Luxeon Driver: Sosen with adjustable 0-10V
- Efficacy: 2.7µmol / J
- PPF: 1700 µmol / s
- Color temperature: 4062K
- Lifespan: L90: 50,000 hours.
- Protection level IP66
