GroLab Peristaltic Pump - 12V Dosing pump
Description
NOTE! All GroLab products have a longer delivery time!
Hose pump NKP / KFS / KXF & Precision
Peristaltic pumps are useful for automating the regulation of pH and nutrients. Add up to 4 units per GroLab TankBot and accurately manage all your liquids.
Tankbot connection
Specifications
| NKP | KFS |
| Voltage: 12VDC | Voltage: 12VDC |
| Consumption: 4.8W~0.4A | Consumption: 3W~0.25A |
| Operating Temperature Range: 0 tot 40°C | Operating Temperature Range: 0 tot 40°C |
| Operating Humidity Range: <80% | Operating Humidity Range: <80% |
| Flow rate: 58ml/min (bereik: 10~60ml/min) | Flow rate: 1~85ml/min |
| Pump tube length: 175 mm lengte (49,5 mm blootgesteld) | Pump tube length: 135mm (30mm blootgesteld) |
| Outer diameter tube: 5 mm | Outer diameter tube: 5 mm |
| Tube inner diameter: 3 mm | Tube inner diameter: 3 mm |
| Tube material: Silicium | Tube material: PharMed®BPT |
Exterior:
| Exterior:
|
| Dimensions: 75x54x40mm | Dimensions: 80x41x58mm |
| Rotors: 3 | |
| Transmission: 1:14 |
| KXF | Precisie |
| Voltage: 12VDC | Voltage: 12VDC |
| Consumption: 3W~0.25A | Consumption: 16W |
| Operating Temperature Range: 0 tot 40°C | - |
| Operating Humidity Range: <80% | - |
| Flow rate: 2~80ml/min | Flow rate: 0.08~280 ml/min |
| - | Pump tube length: 175mm lengte (49,5mm blootgesteld) |
| Outer diameter tube: 4.5 mm | - |
| Tube inner diameter: 2.5 mm | - |
| Tube material: PharMed®BPT | - |
Exterior:
| Exterior:
|
| Dimensions: 71x40x40mm | Dimensions: 63.2x93x164.4mm |
| RPM: 0.1-350* | |
Lifetime: ≥200h* |
